Feature:
1.The products that have been sterilized by our equipment are completely dry when the finished product is produced, and do not need to be dried separately. Can be directly packaged.
2.The pure physical sterilization method is safer, healthier and more environmentally friendly.
3.Unique bottom steam breaking design, let the steam spread more evenly and soft, so as to achieve better sterilization effect.
4.The production capacity is adjusted according to customer requirements, more intimate.
All models can be customized
|
Model |
600-600 |
12-20 |
12-40 |
15-50 |
|
Pot Diameter* Length |
600mm*600mm |
1200mm *2000mm |
1200mm *4000mm |
1500mm*5000mm |
|
Overall size |
2427*815*1079mm |
4855*1630*2157mm |
4855*1630*2157mm |
6107*4200*2684mm |
|
Capacity of powder |
About 8-16KG |
Power about120-170kg |
About 250kg |
About 760kg |
|
Capacity of granulate |
About 16kg |
About 260kg |
About 500kg |
About 1600kg |
|
Pot body thickness |
The inner wall is 10mm thick, the outer jacket is 5mm |
The inner wall is 10mm thick, the outer jacket is 5mm |
The inner wall is 10mm thick, the outer jacket is 6mm |
The inner wall is 14mm thick, the outer jacket is 6mm |
|
Power |
About 10kw |
About 15kw |
About 15kw |
About 30kw |
|
Maximum work pressure |
0.3Mpa |
0.3Mpa |
0.3Mpa |
0.3Mpa |
|
Maximum work temperature |
143°C |
143°C |
143°C |
143°C |
